GRP Boxed Section
GRP Boxed Section is a non-conductive, lightweight, corrosion-resistant profile engineered for demanding environments. Pultruded as a square hollow section, it can be used as a standalone profile or combined into an inter-sliding barrier system.
Our GRP boxed section is constructed from the highest quality glass reinforced plastic making it lightweight, and also chemical, rust, and corrosion resistant whilst offering longevity and durability.
Slip resistant 3
Excellent slip resistance to level 3
Wear resistant 3
Excellent wear resistance to level 3, suitable for heavy footfall
Chemical resistant
Resistant for chemicals and oils
Cut to size
Product can be cut to bespoke sizes
Disability friendly
Suitable for wheelchairs
Dry area
Suitable for use in dry areas
Wet area
Suitable for use in wet environments
Oily and greasy area
Suitable for use in oily and greasy areas
Heavy area
Suitable for use in heavy duty areas
Wheeled area
Suitable for trolleys and wheeled trucks
Flame retardant
For use in fire risk areas
Impact resistant
Able to resist sudden force or shock
Non-conductive (Electrical)
Suitable for use in electrical areas
Non-conductive (HV Electrical)
Suitable for use in high voltage electrical areas
UV resistant
Resistant to UV rays
Features
- GRP boxed section is designed to be used as a stand alone section or inter-sliding barrier system
- A great solution installed to commercial vehicles, safety systems or as a handrail
- Can be easily cut to any length using our in-house cutting service
- Constructed from the highest quality plastic making it lightweight, chemical, rust, and corrosion resistant, ensuring longevity and durability
- Certified to EN 13501: Class B s1 d0 f
- Fixing clips, bolts and clamps are available to purchase separately
Technical Specification
- Fire classification - EN 13501: Class B s1 d0 f
- Laboratory baseline material data:
- Effective flexural modulus, E – 26 GPa
- Tensile modulus – axial – 35 GPa
- Flexural strength – axial - E = 26 GPa; flexural strength >= 340 MPa
- Tensile strength – axial -35 GPa; tensile strength >= 380 MPa
- Interlaminar shear strength – axial - >= 25 MPa
- Interlaminar shear strength – transverse - >= 10 MPa
- Service bending stress screening limit - 120 MPa
- Density range - 1700 - 2000 kg/m3
- Barcol hardness - >45
- Water Absorption, 24h - <=0.45%
Applications
A perfect solution as a handrail, standard profile, or an inter-sliding profile on vehicles or machinery. Used within framing systems and structures of pedestrian walkways, industrial platforms, marine and offshore platforms, data centres and rail infrastructure.
Variants and Sizes
Code | Description | Thickness | Weight (kgs) |
|---|---|---|---|
| GBPS385YL-1003-6000 | GRP Boxed Section 38mm x 38mm x 6m - Yellow | 5mm | 7.5 |
